Field Review - Addition / Alteration - #1200 Exterior and interior alterations to provide improvements to dwelling unit #1200 on the 12th floor of this existing multiple dwelling building on this site. Exterior work to remove a balcony enclosure. Scope of work includes demolition of non-loadbearing walls, new plumbing, electrical fixtures and millwork and interior finishes. OK for DB per B.Hudson OK for Field Review per L.Jayaraman Arch Sch A/B - Ryan Turner AIBC - 604-942-1215 Sch D - Julio Reynel-Gracia P.Eng - 778-998-0709 This building is sprinklered - separate sprinkler permit required for all related work If you are adding any HVAC equipment (including kitchen exhaust, and air make up air systems) that has an energy component such as motors (greater than 1 horse power) burners coils or heat exchangers you must submit Ashrae compliance Heat pumps must be rated no higher than 60 dB(A). It is the responsibility of the owner and the licensed contractor to ensure heat pumps are specified and sited to minimize the sound level transmission along property lines as required by the Noise Control Bylaw #6555.

Apartment

Field Review - Addition / Alteration - #401 Exterior and interior alterations to provide improvements to this dwelling unit #401 on the 4th floor of this multiple dwelling building on this site. Scope of work for the exterior includes the removal of the balcony enclosure and install windows, sliding doors, and guard rail with tempered glass. Interior work includes the removal of non-loadbearing partition wall in the kitchen and en-suite bathroom, renovation to kitchen, new floor finish, and new plumbing fixture in washroom and additional work related to electrical and plumbing. OK for Field Review per L.Williams, December 17, 2019 Notes: 1. Exterior colors to match existing. 2. CRP Schedule A & Architectural Schedule B submitted by Nicholas Waissbluth, 604.612.5095 3. Building Envelope Schedule D submitted by Julio Reynel-Garcia, P.Eng., 778.998.0709 4. Building inspector to determine on site if a separate sprinkler permit is required. 5. Energy Upgrade: L2 - HVAC - Install timers (up to 60 minute), or humidistat for laundry room fan\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t\t

Multiple Dwelling

High Density Housing / Commercial - Addition / Alteration - Elevator Upgrade - Interior alterations to provide elevator upgrades to one (1) elevator at the existing 13-storey multiple dwelling building on this site for CSA-B44-07 upgrade. Scope of work: - Replacement of existing heat detector at top of elevator shaft to smoke detector. - Upgrading existing circuits to addressable as required for elevator recall purposes. - Adding Q=6 new relays for additional recall control and automatic transfer signals for elevator operating on emergency power. Building Review Branch Notes: 1. Related Electrical Permit EP-2017-10238 2. Fire Safety Plan and or Operations Manual to be updated to show alterations. Plans to be submitted to Fire Prevention office for approval Evacuation plans for occupants to be updated. 3. Schedule B - Architectural & Electrical, S.J.F Jacob, P.Eng. Revision #1: Change elevator alternate recall level from 2nd floor to basement parkade, update elevator recall sequence of operations (2/E1.0), add elevator pit heat detector to riser diagram (2/E1.1) and parkade floor plan (1/E1.2), add egress paths to parkade (1/E1.2) and remove from 2nd floor level (1/E1.4), and update reference notes 2 & 3 (Page E1.3) regarding restricted access egress doors. P Volpi, Jan. 29, 2021

Multiple Dwelling
